Flying Marking Machine

ZKF-FXseries

● Suitable for various metal materials such as iron, copper, aluminum, gold, silver, etc.

It is applicable to a variety of non-metallic materials, such as packaging cartons, cartons, PET beverage bottles, mineral water bottles and other non-metallic materials

It is widely used in pharmaceutical electronic supervision code, food, dairy products, beverages, electronic components, integrated circuit (IC), electrical appliances, mobile communication, precision accessories, glasses, clocks, jewelry, auto parts, instruments and meters, sanitary ware, craft gifts, signs and other industries

Product introduction

01 Flight online laser marking is a processing method of using laser to process objects on the production line (that is, the processing object is moving relative to the laser). This processing method greatly improves the processing efficiency compared with static processing, and has been widely used by more and more users.

02 Adapt to customers' mass and continuous production, with high production efficiency;

03 The software can automatically generate serial number (bar code), which is used to quickly realize product attribute identification, batch production and product marking easy to trace, and has good anti-counterfeiting and anti fleeing effect;

04 It can also be applied to the marking of large and heavy workpieces with different shapes and the processing of large molds.



Consult online
Flying Marking Machine

technical specification

  • Product Model
    ZKF-FXseries
  • Equipment Type
    Flying laser marking machine
  • Marking minimum characters
    0.2mm@F=160mm
  • Min. line width
    ≤0.06mm
  • Marking depth
    ≤0.05mm Depends on the material
  • Marking speed
    ≤7000mm/s
  • Operating Voltage
    AC220V/50Hz
  • Whole machine power consumption
    500w
  • Dimension
    880×650×750(mm)
  • Weight of the whole machine
    100kg
  • Marking range
    70×70/110×110/150×150/200×200mm
  • Beam quality
    <1.3-1.8
  • Effective light output
    Laser ≥ 100000H
  • Laser power (w)
    20/30/50/80/100
  • Laser wavelength
    1064nm
  • Applications
    Various metals and non-metals
  • Peak power
    125μj/10KW
  • Repeat positioning accuracy
    ±0.02mm
  • Pulse width
    200ns
  • Pulse repetition rate
    1.6~1000KHz
  • Support for graphic formats
    BMP,PLT,AI,DXF, etc.
  • Working Environment
    Temperature 10 to 35°C, humidity 5 to 85%, no condensation, no dust or less dust.
